Heat Shrinkable Terminations Upto 36 kV For 3 Core PILC/MIND Cable
zoom view
Kit Series: CHT-3PI, CHT-3PO
Ordering Reference
| Cable Size (mm2) | Kit Code (Indoor) |
|---|---|
| 3 x 35 - 70 | 3PI - 36A |
| 3 x 95 - 150 | 3PI - 36B |
| 3 x 185 - 300 | 3PI - 36C |
| 3 x 400 - 500 | 3PI - 36D |
• Indoor Kit does not contain Rainshed
| Cable Size (mm2) | Kit Code (Outdoor) |
|---|---|
| 3 x 35 - 70 | 3PO - 36A |
| 3 x 95 - 150 | 3PO - 36B |
| 3 x 185 - 300 | 3PO - 36C |
| 3 x 400 - 500 | 3PO - 36D |
Technical Specifications
| Test Sequence | Requirements |
|---|---|
| D.C. Voltage Withstand / 15 min | 144 kV |
| A.C. Voltage Dry Withstand / 1 min | 75 kV |
| Impulse Withstand | 170 kV |
