Heat Shrinkable Terminations Upto 36 Kv Suitable for 1 Core XLPE/EPR Insulated Cables
zoom view
Kit Series: CHT-1XI, CHT-1XO
Ordering Reference
| Cable Size (mm2) | Kit Code (Indoor) |
|---|---|
| 1 x 25 - 50 | 1XI - 36A |
| 1 x 70 - 185 | 1XI - 36B |
| 1 x 240 - 400 | 1XI - 36C |
| 1 x 500 - 800 | 1XI - 36D |
| 1 x 1000 | 1XI - 36E |
| Cable Size (mm2) | Kit Code (Outdoor) |
|---|---|
| 1 x 25 - 50 | 1X0 - 36A |
| 1 x 70 - 185 | 1XO - 36B |
| 1 x 240 - 400 | 1XO - 36C |
| 1 x 500 - 800 | 1XO - 36D |
| 1 x 1000 | 1XO - 36E |
Technical Specifications
| Test Sequence | Requirements |
|---|---|
| D.C. Voltage Withstand / 15 min | 144 kV |
| A.C. Voltage Dry Withstand / 1 min | 75 kV |
| Impulse Withstand | 170 kV |
| Discharge extinction Voltage | > 38 kV |
