Heatshrinkable Straight Joint Upto 36 kV For AB Cable

zoom view

Kit Series: CHJ-1ABS

Ordering Reference

Cable Size mm2 11 /15 KV(Kit Code)
1 x 16-50 1ABS - 15A
1 x 70-120 1ABS - 15B
1 x 150-225 1ABS - 15C
1 x 240-300 1ABS - 15D
1 x 400-500 1ABS - 15E
1 x 630-1000 1ABS - 15F

Cable Size mm2 22/24 kV (Kit Code)
1 x 25 - 50 1ABS - 24A
1 x 70 - 150 1ABS - 24B
1 x 185 - 240 1ABS - 24C
1 x 300 - 500 1ABS - 24D
1 x 630 - 800 1ABS - 24E
1 x 1000 1ABS - 24F

Cable Size mm2 33/36 kV (Kit Code)
1 x 35 - 70 1ABS - 36A
1 x 95 - 150 1ABS - 36B
1 x 185 - 400 1ABS - 36C
1 x 500 - 630 1ABS - 36D
1 x 800 - 1000 1ABS - 36E

Technical specifications

Test Sequence Requirements for 15kV Requirements for 24kV Requirements for 36kV
A/C withstand/ 5 Min 29 kV 58 kV 86 kV
Partial discharge test 11kV<10pc (Max.) 22kV<10pc (Max.) 33kV<10pc (Max.)
Impulses voltage 75 kV 125 kV 170 kV
A/C with stand / 15min 16kV 32kV 48kV
