Heat Shrinkable Terminations Upto 15 Kv Suitable For 1 Core XLPE/EPR Insulated Cable
zoom view
Kit Series : CHT-1XI,CHT-1XO
Ordering Reference
| Cable Size (mm2) | Kit Code (Indoor) |
|---|---|
| 1 x 16 - 50 | 1XI - 15A |
| 1 x 70 - 120 | 1XI - 15B |
| 1 x 150 - 300 | 1XI - 15C |
| 1 x 400 - 630 | 1XI - 15D |
| 1 x 800 - 1000 | 1XI - 15E |
• Indoor Kit does not contain Rainshed
| Cable Size (mm2) | Kit Code (Outdoor) |
|---|---|
| 1 x 16 - 50 | 1XO - 15A |
| 1 x 70 - 120 | 1XO - 15B |
| 1 x 150 - 300 | 1XO - 15C |
| 1 x 400 - 630 | 1XO - 15D |
| 1 x 800 - 1000 | 1XO - 15E |
Technical Specifications
| Test Sequence | Requirements |
|---|---|
| D.C. Voltage Withstand / 15 min | 48 kV |
| A.C. Voltage Dry Withstand / 1 min | 35 kV |
| Impulse Withstand | 75 kV |
| Discharge extinction Voltage | > 13 kV |
