Heat Shrinkable Terminations Upto 24 kV Suitable for 3 core XLPE/EPR Insulated cables
zoom view
Kit Series: CHT-3XI, CHT-3XO
Ordering Reference
| Cable Size (mm2) | Kit Code (Indoor) |
|---|---|
| 16-50 | 3XI - 24A |
| 70-120 | 3XI - 24B |
| 150-185 | 3XI - 24C |
| 240-400 | 3XI - 24D |
• Indoor Kit does not contain Rainshed
| Cable Size (mm2) | Kit Code (Outdoor) |
|---|---|
| 16-50 | 3XO - 24A |
| 70-120 | 3XO - 24B |
| 150-185 | 3XO - 24C |
| 240-400 | 3XO - 24D |
Technical Specifications
| Test Sequence | Requirements |
|---|---|
| D.C. Voltage Withstand / 15 min | 96 kV |
| A.C. Voltage Dry Withstand / 1 min | 50 kV |
| Impulse Withstand | 125 kV |
| Discharge extinction Voltage | > 25 kV |
